ADL107 Series Digital Thermostat
 |
Add to Inquiry Basket
View Inquiry Basket
The products that you selected had been put into inquiry basket !
 |
ADL107 series thermostats are used to control room temperature in industrial, commercial and residential environment via controlling the fan coil units (With or without motorized valve),dampers, diffuser etc., which uses NTC to detect the room temperature and compareit with the set-point so as to automatically keep the room temperature stable. |
| Features: |
| To control fan coil, valve and damper etc |
| Manual switch to select work state and use knob to set the temperature |
| Thermostats can be directly mounted on the wall or standard wiring box |
| Elegant shape with high reliability |
| Main Functions |
| Turning On/Off |
Cool/Heat Exchange Control |
| Fan Speed Adjustable | Room Temperature Setting |
| Specifications |
|
Sensor |
NTC |
|
Set-point Range |
10~30℃ |
|
Accuracy |
±1℃ |
|
Power Consumption |
<2W |
|
Dimension |
86×130×43mm (W×H×D) |
|
Max. Load |
<150W |
|
Shell |
Fire retardant PC ABS |
|
Power Supply |
220VAC ±10％, 50/60Hz |
