Low Voltage Fuse Bases

Return

Bookmark This Page

Print This Page

Contact Online

Asia :

　　　　　　　　　　　　Europe & Africa :

Middle East Area :

　　　　Oceania & America :

E-Mail : sales@elecal.com

Catalogue Download (PDF Files)

Add to Inquiry Basket　　

View Inquiry Basket

RT16-000

RT16-000

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
RT16-000	RT16-000 RT16-00 NT000 NT00 NH00C NH00	690	160	193

RT16-0

RT16-0

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
RT16-0	RT16-0 NT0 NH0	690	160	295

RT16-1

RT16-1

Types	The model No for corresponing fuse	Rate voltage (V)	Rate current(A)	Weight(g)
RT16-1	RT16-1 NT1 NH1	690	250	550
RT16-2	RT16-2 NT2 NH2	690	400	770
RT16-3	RT16-3 NT3 NH3	690	630	965

NT1S

NT1S

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	Dimension(mm)
Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	A1	A2	B1	H1	H2
NT1S	RT16-1 NT1 NH1	660	250	604	175	200	50	38	82
NT2S	RT16-2 NT2 NH2	660	400	1006	200	230	64	54	104
NT3S	NT16-3 NT2 NH2	660	630	1200	210	250	64	54	120

NH00

NH00

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
NH00	RT16-000/00 NT000/00	660	160	170

NH00-3J

NH00-3J

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current	Weight(g)
NH00-3J	RT16-000/00 NT000/00	660	160	170

NH00-3J

NH00-3J

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
NH00-3J	RT16-000/00 NT000/00	660	160	170

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
NH4S	RT16-4 NT4 NH4	660	1000	3250

NH4S

NH4S

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
NH00-3J	RT16-2 NT2 NH2	660	400	3600

RT0-100

RT0-100

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	Dimension(mm)
Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	A1	A2	B1	H1
RT0-100	RTO-100	400	100	545	180	160	55	73
RT0-200	RTO-200	400	200	760	200	175	60	85
RT0-300	RTO-300	400	400	1065	220	190	70	95

RT0-600

RT0-600

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
RT0-600	RTO-600	400	600	1760

RT0-1000

RT0-1000

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)
RT0-1000	RT0-1000	400	1000	3800

NH0

NH1

NH2

NH0

NH1

NH2

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	Figure
NH0	RT16-0 NT0	660	160	294	Fig1
NH1	NT16-1 NT1	660	250	502	Fig2
NH2	NT16-2 NT2	660	400	526	Fig3

NH0

Fig1

NH1

Fig2

NH2

Fig3

NH3

NH00S1

NH00S2

NH3

NH00S1

NH00S2

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	Figure
NH3	RT16-3 NT3	660	630	762	Fig4
NH00S1	NT16-000/00 NT00C/00	660	160	240	Fig5
NH00S2	NT16-000/00 NT00C/00	660	160	296	Fig6

NH3

Fig4

NH00S1

Fig5

NH00S2

Fig6

NT0S

RT16-4

RT0-50

NT0S

RT16-4

RT0-50

Types	The model No for corresponing fuse	Rate voltage(V)	Rate current(A)	Weight(g)	Figure
NT0S	NH0 NT0 NT16-0	660	160	32	Fig7
RT16-4	RT16-4 NT4 NH4	690	1000	3400	Fig8
RT0-50	RTO-50	400	50	190	Fig9

NT0S

Fig7

NT0S

Fig8

RT0-50

Fig9
