1.Description
Mounting Bracket
Long Bolts
Mounting Bracket
External-Tooth Lock Washer
Porcelain Insulator
Lock Washer
Upper Connection1. Description
Fuse Holder
Lower Connection
Lifting Eye
Connectors
Steady Contacts
Load Break Tool Attack Hook
Opening Eye

2.Specification

Type	Rated Voltage (KV)	Rated Current (A)	Breaking Current (A)	Impulse Voltage (BIL)	Power-Frequency Withstand Voltage (KV)	Crawling Distance	Weight (kg)
RS-7	15	100	10000	110	42	230m/m	7
RS-7	15	100	12000	110	42	230m/m	7
RH-8	15	100	10000	110	42	230m/m	7.3
RH-8	15	100	12000	110	42	230m/m	7.3
RH-C	15	100	10000	110	42	320m/m	7.5
RH-C	15	100	12000	110	42	320m/m	7.5
RH-A	35	100	6000	180	70	800m/m	25
RH-A	35	100	8000	180	70	800m/m	25
R-98	18	100	8000	125	45	340m/m	8.8
R-98	18	100	10000	125	45	340m/m	8.8
R-97	24	100	8000	150	50	500m/m	12
R-97	24	100	10000	150	50	500m/m	12
RH-8	35	100	6000	170	70	660m/m	15
RH-8	35	100	8000	170	70	660m/m	15
RW10-10F/100	12	100	6300	70	42	230m/m	7
RW10-10F/100	12	200	6300	70	42	230m/m	7
RW11-10F-100	12	100	6300	70	42	330m/m	3.5
RW11-10F/100	12	200	6300	70	42	330m/m	3.5
PRWG-10F/100	12	100	6300	70	42	340m/m	8.5
PRWG-10F/100	12	200	6300	70	42	340m/m	8.5
