5KA-10KA Gapped arrester electrical character

Return

Bookmark This Page

Print This Page

Contact Online

Asia :

　　　　　　　　　　　　Europe & Africa :

Middle East Area :

　　　　Oceania & America :

E-Mail : sales@elecal.com

Catalogue Download (PDF Files)

Add to Inquiry Basket　　

View Inquiry Basket

Type	Rated Voltage(KT)	MCOV(KT)	sparkover voltage(KT)			8/20μs Lightning Impulse residual voltage(KV)	2000μs square wave impulse current withstand	4/μs high current impulse
Type	Rated Voltage(KT)	MCOV(KT)	Power frequency		1.2/50μs Lightning impulse	8/20μs Lightning Impulse residual voltage(KV)	2000μs square wave impulse current withstand	4/μs high current impulse
Y5C-3	3	2.55	5.0		7.8	9	100	65
Y5C-6	6	5.1	10.0		15.5	18	100	65
Y5C-9	9	7.65	16.5		24.5	27	100	65
Y5C-12	12	1.2	21.0		32.6	36	100	65
Y5C-15	15	12.7	25.0		38.8	45	100	65
Y5C-18	18	15.3	31.0		48.1	54	100	65
Y5C-21	21	17.0	34.0		52.7	63	100	65
Y5C-24	24	19.2	39.0		60.5	72	100	65
Y5C-27	27	21.9	45.0		69.8	81	100	65
Y5C-30	30	24.4	50.0		77.5	90	100	65
Y5C-33	33	26.8	55.0		85.3	99	100	65
Y5C-36	36	29	60.0		93.0	108	100	65
Y5C-42	42	34.1	70.0		108.5	126	100	65

Type	Rated Voltage(KT)	MCOV(KT)	sparkover voltage(KT)			8/20μs Lightning Impulse residual voltage(KV)	2000μs square wave impulse current withstand	4/μs high current impulse
Type	Rated Voltage(KT)	MCOV(KT)	Power frequency		1.2/50μs Lightning impulse	8/20μs Lightning Impulse residual voltage(KV)	2000μs square wave impulse current withstand	4/μs high current impulse
Y5C-3	3	2.55	9.5		7.7	9	1	100
Y5C-6	6	5.1	19.5		15.4	18	1	100
Y5C-9	9	7.65	28.5		23.1	27	1	100
Y5C-12	12	1.2	38.0		30.8	36	1	100
Y5C-15	15	12.7	47.5		38.5	45	1	100
Y5C-18	18	15.3	57.0		46.2	54	1	100
Y5C-21	21	17.0	66.5		53.9	63	1	100
Y5C-24	24	19.2	76.0		61.6	72	1	100
Y5C-27	27	21.9	85.5		69.3	81	1	100
Y5C-30	30	24.4	95.0		76.5	90	1	100
Y5C-33	33	26.8	104.5		84.7	99	1	100
Y5C-36	36	29	114.0		92.4	108	1	100
Y5C-42	42	34.1	132.3		100.1	126	1	100
