1.Specification

Max. Current: 10A Metal: Brass Insulated Material: Nylon

Item.No.	Specification	Dimension(mm)							Fig	A.W.G mm2	Color
		W	F	L	B	D	C	T
FDFN 1.25-250	0.8 x 6.35	6.6	7.3	22.0	11.0	4.0	1.7	0.4	1	22-16A.W.G 0.5-1.5mm2	Red
MDFN 1.25-250		6.35	7.7	23.0					2

Max. Current: 15A Metal: Brass Insulated Material: Nylon

Item.No.	Specification	Dimension(mm)							Fig	A.W.G mm2	Color
		W	F	L	B	D	C	T
FDFN 2-250	0.8 x 6.35	6.6	7.3	22.0	11.0	4.0	2.3	0.4	1	16-14A.W.G 1.5-2.5mm2	Blue
MDFN 2-250		6.35	7.7	24.0					2

Max. Current: 24A Metal: Brass Insulated Material: Nylon

Item.No.	Specification	Dimension(mm)							Fig	A.W.G mm2	Color
		W	F	L	B	D	C	T
FDFN 5.5-250	0.8 x 6.35	6.6	7.3	22.0	13.0	6.3	3.4	0.4	1	12-10A.W.G 4-6mm2	Yellow
MDFN 5.5-250		6.35	7.7	25.0					2
